Main Features:
- 1/2.8” Sony 2.13M pixels CMOS
- Resolution: 1080P@30fps
- Lens 2.8 \ 3.6 mm optional
- IR distance: 10~15m
- Compact size, light weight
Overview:
Angeltrax mini camera HDSM3600- C24 housing is made of metal and built to survive in rugged and vandal susceptible environments. Vibration and thermal tested, the powerful camera is an excellent choice for various mobile environments. Utilising the Sony CMOS imaging sensor, it provides outstanding image quality in both day and night lighting conditions.
Specification:
| Model | HDSM3600 Rear Camera |
| Sensor | 1/2.8” Sony 2.13M pixels CMOS |
| Resolution | 1920*1080 |
| Minimum illumination | 0LUX (IR on) |
| S/N | ≥50dB |
| Sync system | Inter-sync |
| Scanning system | Progressive scanning |
| Lens | 2.8/3.6mm optional |
| Electronic shutter | Auto |
| White balance mode | Auto |
| Colour to black | External synchronisation control |
| Gamma correction | 0.55 |
| IR distance | 10m-15m ( LED*1) |
| Video output | AHD coaxial HD standard, 4-pin DIN JACK |
| Power | DC12V± 10% |
| Consumption(Max.) | 230mA/DC12V(IR on) |
| Working temperature | -20°C ~ +55°C |
Video Output:
